Deep Learning básico con Keras (Parte 3): VGG

Publicado por Jesús Utrera Burgal el

Deep LearningKerasVGG

Seguimos la serie sobre Deep Learning básico. Tras la introducción a Keras y redes convolucionales, en este tercer artículo vamos a mostrar una red VGG.

Introducida en el siguiente paper, Very Deep Convolutional Networks for Large-Scale Image Recognition, es una de las primeras redes profundas más conocidas. Os muestro en las dos imágenes siguientes el modelo y sus especificaciones:

Diagrama de arquitectura general VGG

Arquitecturas VGG

Realizaremos el mismo experimento que en las partes anteriores. Obviaremos los puntos en los que importamos el dataset de CIFAR-100, la configuración básica del entorno del experimento y la importación de las librerías de python, pues son exactamente igual.

Entrenando la arquitectura VGG-16

Keras tiene a nuestra disposición tanto la arquitectura VGG-16 como la VGG-19. Vamos a entrenar ambas y una más que explicaremos en breve. Debido a que vamos a usar la definida en Keras (aunque podríamos crearla directamente), debemos aumentar el tamaño de las imágenes a 48 píxeles. Para ello, usaremos el siguiente código:

def resize_data(data):
    data_upscaled = np.zeros((data.shape[0], 48, 48, 3))
    for i, img in enumerate(data):
        large_img = cv2.resize(img, dsize=(48, 48), interpolation=cv2.INTER_CUBIC)
        data_upscaled[i] = large_img

    return data_upscaled

x_train_resized = resize_data(x_train_original)
x_test_resized = resize_data(x_test_original)
x_train_resized = x_train_resized / 255
x_test_resized = x_test_resized / 255

Con esto, tenemos las imágenes a 48 píxeles normalizadas en x_train_resized y x_test_resized. Como dijimos antes, entrenaremos los modelos VGG-16, VGG-19 y uno más. Esta es nuestra propia versión de VGG con objeto de no tener que modificar el tamaño de las imágenes. Empezaremos entrenando VGG-16, veremos resultados y continuaremos con VGG-19 para terminar con nuestra Custom VGG.

VGG-16

Definimos el modelo. Tan fácil como llamar al existente en Keras:

from keras.applications import vgg16

def create_vgg16():
  model = vgg16.VGG16(include_top=True, weights=None, input_tensor=None, input_shape=(48,48,3), pooling=None, classes=100)

  return model

Los parámetros son sencillos: vamos a incluir una red neuronal densa al final con el parámetro include_top. No cargamos ningún modelo entrenado a priori con el parámetro weights. No especificamos ningún tensor de keras como entrada con input_tensor. Definimos la forma de los datos de entrada con input_shape, No especificamos Pooling final con pooling y definimos el número de clases final con classes.

Una vez definido el modelo, lo compilamos especificando la función de optimización, la de coste o pérdida y las métricas que usaremos. En este caso, como en los artículos anteriores, usaremos la función de optimización stochactic gradient descent, la función de pérdida categorical cross entropy y, para las métricas, accuracy y mse (media de los errores cuadráticos).

vgg16_model = create_vgg16()
vgg16_model.compile(loss='categorical_crossentropy', optimizer='sgd', metrics=['acc', 'mse'])

Una vez hecho esto, vamos a ver un resumen del modelo creado:

vgg16_model.summary()

_________________________________________________________________
Layer (type)                 Output Shape              Param #
=================================================================
input_1 (InputLayer)         (None, 48, 48, 3)         0
_________________________________________________________________
block1_conv1 (Conv2D)        (None, 48, 48, 64)        1792
_________________________________________________________________
block1_conv2 (Conv2D)        (None, 48, 48, 64)        36928
_________________________________________________________________
block1_pool (MaxPooling2D)   (None, 24, 24, 64)        0
_________________________________________________________________
block2_conv1 (Conv2D)        (None, 24, 24, 128)       73856
_________________________________________________________________
block2_conv2 (Conv2D)        (None, 24, 24, 128)       147584
_________________________________________________________________
block2_pool (MaxPooling2D)   (None, 12, 12, 128)       0
_________________________________________________________________
block3_conv1 (Conv2D)        (None, 12, 12, 256)       295168
_________________________________________________________________
block3_conv2 (Conv2D)        (None, 12, 12, 256)       590080
_________________________________________________________________
block3_conv3 (Conv2D)        (None, 12, 12, 256)       590080
_________________________________________________________________
block3_pool (MaxPooling2D)   (None, 6, 6, 256)         0
_________________________________________________________________
block4_conv1 (Conv2D)        (None, 6, 6, 512)         1180160
_________________________________________________________________
block4_conv2 (Conv2D)        (None, 6, 6, 512)         2359808
_________________________________________________________________
block4_conv3 (Conv2D)        (None, 6, 6, 512)         2359808
_________________________________________________________________
block4_pool (MaxPooling2D)   (None, 3, 3, 512)         0
_________________________________________________________________
block5_conv1 (Conv2D)        (None, 3, 3, 512)         2359808
_________________________________________________________________
block5_conv2 (Conv2D)        (None, 3, 3, 512)         2359808
_________________________________________________________________
block5_conv3 (Conv2D)        (None, 3, 3, 512)         2359808
_________________________________________________________________
block5_pool (MaxPooling2D)   (None, 1, 1, 512)         0
_________________________________________________________________
flatten (Flatten)            (None, 512)               0
_________________________________________________________________
fc1 (Dense)                  (None, 4096)              2101248
_________________________________________________________________
fc2 (Dense)                  (None, 4096)              16781312
_________________________________________________________________
predictions (Dense)          (None, 100)               409700
=================================================================
Total params: 34,006,948
Trainable params: 34,006,948
Non-trainable params: 0
_________________________________________________________________

Ahora el número de parámetros ha crecido sustancialmente (34 millones). Ahora sólo queda entrenar:

vgg16 = vgg16_model.fit(x=x_train_resized, y=y_train, batch_size=32, epochs=10, verbose=1, validation_data=(x_test_resized, y_test), shuffle=True)
Train on 50000 samples, validate on 10000 samples
Epoch 1/10
50000/50000 [==============================] - 173s 3ms/step - loss: 4.6053 - acc: 0.0095 - mean_squared_error: 0.0099 - val_loss: 4.6049 - val_acc: 0.0164 - val_mean_squared_error: 0.0099
Epoch 2/10
 50000/50000 [==============================] - 171s 3ms/step - loss: 4.6050 - acc: 0.0114 - mean_squared_error: 0.0099 - val_loss: 4.6045 - val_acc: 0.0160 - val_mean_squared_error: 0.0099
Epoch 3/10
 50000/50000 [==============================] - 171s 3ms/step - loss: 4.6041 - acc: 0.0158 - mean_squared_error: 0.0099 - val_loss: 4.6028 - val_acc: 0.0200 - val_mean_squared_error: 0.0099
Epoch 4/10
 50000/50000 [==============================] - 171s 3ms/step - loss: 4.6001 - acc: 0.0185 - mean_squared_error: 0.0099 - val_loss: 4.5940 - val_acc: 0.0110 - val_mean_squared_error: 0.0099
Epoch 5/10
 50000/50000 [==============================] - 171s 3ms/step - loss: 4.4615 - acc: 0.0278 - mean_squared_error: 0.0099 - val_loss: 4.3003 - val_acc: 0.0519 - val_mean_squared_error: 0.0098
Epoch 6/10
 50000/50000 [==============================] - 171s 3ms/step - loss: 4.1622 - acc: 0.0687 - mean_squared_error: 0.0097 - val_loss: 4.1022 - val_acc: 0.0765 - val_mean_squared_error: 0.0097
Epoch 7/10
 50000/50000 [==============================] - 171s 3ms/step - loss: 4.0242 - acc: 0.0888 - mean_squared_error: 0.0097 - val_loss: 4.0127 - val_acc: 0.0939 - val_mean_squared_error: 0.0097
Epoch 8/10
 50000/50000 [==============================] - 171s 3ms/step - loss: 3.9118 - acc: 0.1052 - mean_squared_error: 0.0096 - val_loss: 4.0327 - val_acc: 0.0963 - val_mean_squared_error: 0.0096
Epoch 9/10
 50000/50000 [==============================] - 171s 3ms/step - loss: 3.7884 - acc: 0.1235 - mean_squared_error: 0.0095 - val_loss: 3.7928 - val_acc: 0.1276 - val_mean_squared_error: 0.0094
Epoch 10/10
 50000/50000 [==============================] - 171s 3ms/step - loss: 3.6518 - acc: 0.1429 - mean_squared_error: 0.0094 - val_loss: 3.8205 - val_acc: 0.1316 - val_mean_squared_error: 0.0095

Obviaremos la evaluación.

Veamos las métricas obtenidas para el entrenamiento y validación gráficamente:

plt.figure(0)
plt.plot(vgg16.history['acc'],'r')
plt.plot(vgg16.history['val_acc'],'g')
plt.xticks(np.arange(0, 11, 2.0))
plt.rcParams['figure.figsize'] = (8, 6)
plt.xlabel("Num of Epochs")
plt.ylabel("Accuracy")
plt.title("Training Accuracy vs Validation Accuracy")
plt.legend(['train','validation'])

plt.figure(1)
plt.plot(vgg16.history['loss'],'r')
plt.plot(vgg16.history['val_loss'],'g')
plt.xticks(np.arange(0, 11, 2.0))
plt.rcParams['figure.figsize'] = (8, 6)
plt.xlabel("Num of Epochs")
plt.ylabel("Loss")
plt.title("Training Loss vs Validation Loss")
plt.legend(['train','validation'])

plt.show()

Accuracy

Loss

La generalización mejora a un 1% aproximadamente respecto a la red convolucional del experimento anterior, si bien, después de 10 epochs no ha mejorado las métricas estándar.

Matriz de confusión

Pasemos ahora a ver la matriz de confusión y las métricas de Accuracy, Recall y F1-score.

Vamos a hacer una predicción sobre el dataset de validación y, a partir de ésta, generamos la matriz de confusión y mostramos las métricas mencionadas anteriormente:

vgg16_pred = vgg16_model.predict(x_test_resized, batch_size=32, verbose=1)
vgg16_predicted = np.argmax(vgg16_pred, axis=1)

Como ya hiciéramos en la primera parte, vamos a dar como predicha el mayor valor de la predicción. Lo normal es dar un valor mínimo o bias que defina un resultado como positivo, pero en este caso, lo vamos a hacer simple.

Con la librería Scikit Learn, generamos la matriz de confusión y la dibujamos (aunque el gráfico no es muy bueno debido al numero de etiquetas).

#Creamos la matriz de confusión
vgg16_cm = confusion_matrix(np.argmax(y_test, axis=1), vgg16_predicted)

# Visualiamos la matriz de confusión
vgg16_df_cm = pd.DataFrame(vgg16_cm, range(100), range(100))
plt.figure(figsize = (20,14))
sn.set(font_scale=1.4) #for label size
sn.heatmap(vgg16_df_cm, annot=True, annot_kws={"size": 12}) # font size
plt.show()

Matriz de confusión

Y por último, mostramos las métricas:

vgg16_report = classification_report(np.argmax(y_test, axis=1), vgg16_predicted)
print(vgg16_report)

             precision    recall  f1-score   support

          0       0.63      0.27      0.38       100
          1       0.10      0.14      0.11       100
          2       0.04      0.04      0.04       100
          3       0.01      0.01      0.01       100
          4       0.02      0.01      0.01       100
          5       0.05      0.04      0.05       100
          6       0.16      0.03      0.05       100
          7       0.11      0.11      0.11       100
          8       0.06      0.01      0.02       100
          9       0.31      0.18      0.23       100
         10       0.14      0.18      0.15       100
         11       0.20      0.01      0.02       100
         12       0.11      0.31      0.16       100
         13       0.09      0.26      0.13       100
         14       0.13      0.10      0.11       100
         15       0.00      0.00      0.00       100
         16       0.16      0.25      0.19       100
         17       0.17      0.40      0.24       100
         18       0.00      0.00      0.00       100
         19       0.09      0.03      0.04       100
         20       0.52      0.25      0.34       100
         21       0.06      0.07      0.07       100
         22       0.21      0.20      0.21       100
         23       0.14      0.38      0.21       100
         24       0.28      0.30      0.29       100
         25       0.07      0.09      0.08       100
         26       0.10      0.03      0.05       100
         27       0.07      0.03      0.04       100
         28       0.35      0.24      0.28       100
         29       0.06      0.14      0.09       100
         30       0.12      0.55      0.20       100
         31       0.08      0.08      0.08       100
         32       0.30      0.06      0.10       100
         33       0.17      0.05      0.08       100
         34       0.06      0.05      0.06       100
         35       0.06      0.04      0.05       100
         36       0.06      0.02      0.03       100
         37       0.08      0.14      0.10       100
         38       0.04      0.01      0.02       100
         39       0.08      0.08      0.08       100
         40       0.27      0.21      0.24       100
         41       0.50      0.45      0.47       100
         42       0.05      0.09      0.07       100
         43       0.15      0.06      0.09       100
         44       0.07      0.01      0.02       100
         45       0.00      0.00      0.00       100
         46       0.08      0.01      0.02       100
         47       0.20      0.11      0.14       100
         48       0.17      0.11      0.13       100
         49       0.29      0.07      0.11       100
         50       0.00      0.00      0.00       100
         51       0.16      0.03      0.05       100
         52       0.14      0.85      0.24       100
         53       0.23      0.11      0.15       100
         54       0.25      0.03      0.05       100
         55       0.09      0.02      0.03       100
         56       0.09      0.30      0.14       100
         57       0.33      0.08      0.13       100
         58       0.03      0.01      0.01       100
         59       0.00      0.00      0.00       100
         60       0.56      0.51      0.53       100
         61       0.28      0.28      0.28       100
         62       0.18      0.34      0.23       100
         63       0.08      0.05      0.06       100
         64       0.10      0.03      0.05       100
         65       0.08      0.02      0.03       100
         66       0.02      0.01      0.01       100
         67       0.03      0.01      0.01       100
         68       0.29      0.58      0.39       100
         69       0.18      0.09      0.12       100
         70       0.00      0.00      0.00       100
         71       0.27      0.47      0.34       100
         72       0.10      0.16      0.12       100
         73       0.33      0.02      0.04       100
         74       0.00      0.00      0.00       100
         75       0.10      0.40      0.16       100
         76       0.14      0.37      0.20       100
         77       0.05      0.01      0.02       100
         78       0.00      0.00      0.00       100
         79       0.00      0.00      0.00       100
         80       0.03      0.01      0.01       100
         81       0.05      0.10      0.06       100
         82       0.25      0.23      0.24       100
         83       0.43      0.06      0.11       100
         84       0.13      0.02      0.03       100
         85       0.17      0.10      0.13       100
         86       0.23      0.13      0.17       100
         87       0.08      0.01      0.02       100
         88       0.03      0.03      0.03       100
         89       0.17      0.06      0.09       100
         90       0.14      0.02      0.04       100
         91       0.12      0.38      0.18       100
         92       0.00      0.00      0.00       100
         93       0.05      0.09      0.06       100
         94       0.19      0.16      0.17       100
         95       0.09      0.39      0.15       100
         96       0.06      0.01      0.02       100
         97       0.04      0.18      0.07       100
         98       0.04      0.02      0.03       100
         99       0.11      0.07      0.09       100

avg / total       0.14      0.13      0.11     10000

Curva ROC (tasas de verdaderos positivos y falsos positivos)

Vamos a codificar la curva ROC para clasificación multiclase. Como hemos dicho en los artículos anteriores, el código está obtenido del blog de DloLogy, pero se puede obtener de la documentación de Scikit Learn:

from sklearn.datasets import make_classification
from sklearn.preprocessing import label_binarize
from scipy import interp
from itertools import cycle

n_classes = 100

from sklearn.metrics import roc_curve, auc

# Plot linewidth.
lw = 2

# Compute ROC curve and ROC area for each class
fpr = dict()
tpr = dict()
roc_auc = dict()
for i in range(n_classes):
    fpr[i], tpr[i], _ = roc_curve(y_test[:, i], vgg16_pred[:, i])
    roc_auc[i] = auc(fpr[i], tpr[i])

# Compute micro-average ROC curve and ROC area
fpr["micro"], tpr["micro"], _ = roc_curve(y_test.ravel(), vgg16_pred.ravel())
roc_auc["micro"] = auc(fpr["micro"], tpr["micro"])

# Compute macro-average ROC curve and ROC area

# First aggregate all false positive rates
all_fpr = np.unique(np.concatenate([fpr[i] for i in range(n_classes)]))

# Then interpolate all ROC curves at this points
mean_tpr = np.zeros_like(all_fpr)
for i in range(n_classes):
    mean_tpr += interp(all_fpr, fpr[i], tpr[i])

# Finally average it and compute AUC
mean_tpr /= n_classes

fpr["macro"] = all_fpr
tpr["macro"] = mean_tpr
roc_auc["macro"] = auc(fpr["macro"], tpr["macro"])

# Plot all ROC curves
plt.figure(1)
plt.plot(fpr["micro"], tpr["micro"],
         label='micro-average ROC curve (area = {0:0.2f})'
               ''.format(roc_auc["micro"]),
         color='deeppink', linestyle=':', linewidth=4)

plt.plot(fpr["macro"], tpr["macro"],
         label='macro-average ROC curve (area = {0:0.2f})'
               ''.format(roc_auc["macro"]),
         color='navy', linestyle=':', linewidth=4)

colors = cycle(['aqua', 'darkorange', 'cornflowerblue'])
for i, color in zip(range(n_classes-97), colors):
    plt.plot(fpr[i], tpr[i], color=color, lw=lw,
             label='ROC curve of class {0} (area = {1:0.2f})'
             ''.format(i, roc_auc[i]))

plt.plot([0, 1], [0, 1], 'k--', lw=lw)
plt.xlim([0.0, 1.0])
plt.ylim([0.0, 1.05])
plt.xlabel('False Positive Rate')
plt.ylabel('True Positive Rate')
plt.title('Some extension of Receiver operating characteristic to multi-class')
plt.legend(loc="lower right")
plt.show()


# Zoom in view of the upper left corner.
plt.figure(2)
plt.xlim(0, 0.2)
plt.ylim(0.8, 1)
plt.plot(fpr["micro"], tpr["micro"],
         label='micro-average ROC curve (area = {0:0.2f})'
               ''.format(roc_auc["micro"]),
         color='deeppink', linestyle=':', linewidth=4)

plt.plot(fpr["macro"], tpr["macro"],
         label='macro-average ROC curve (area = {0:0.2f})'
               ''.format(roc_auc["macro"]),
         color='navy', linestyle=':', linewidth=4)

colors = cycle(['aqua', 'darkorange', 'cornflowerblue'])
for i, color in zip(range(3), colors):
    plt.plot(fpr[i], tpr[i], color=color, lw=lw,
             label='ROC curve of class {0} (area = {1:0.2f})'
             ''.format(i, roc_auc[i]))

plt.plot([0, 1], [0, 1], 'k--', lw=lw)
plt.xlabel('False Positive Rate')
plt.ylabel('True Positive Rate')
plt.title('Some extension of Receiver operating characteristic to multi-class')
plt.legend(loc="lower right")
plt.show()

El resultado para tres clases se muestra en los siguientes gráficos:

Curva ROC para 3 clases

Zoom de la Curva ROC para 3 clases

Vamos a ver algunos resultados:

imgplot = plt.imshow(x_train_original[0])
plt.show()
print('class for image 1: ' + str(np.argmax(y_test[0])))
print('predicted:         ' + str(vgg16_predicted[0]))

Una vaca?

class for image 1: 49
predicted: 95

imgplot = plt.imshow(x_train_original[3])
plt.show()
print('class for image 3: ' + str(np.argmax(y_test[3])))
print('predicted:         ' + str(vgg16_predicted[3]))

Un hombre?

class for image 3: 51
predicted: 75

Salvaremos los datos del histórico de entrenamiento para compararlos con otros modelos:

#Histórico
with open(path_base + '/vgg16_history.txt', 'wb') as file_pi:
  pickle.dump(scnn.history, file_pi)

VGG-19

Definamos el modelo y entrenemos de la misma forma que VGG-16.

def create_vgg19():
  model = vgg19.VGG19(include_top=True, weights=None, input_tensor=None, input_shape=(48,48,3), pooling=None, classes=100)

  return model

vgg19_model = create_vgg19()
vgg19_model.compile(loss='categorical_crossentropy', optimizer='sgd', metrics=['acc', 'mse'])

Una vez hecho esto, vamos a ver un resumen del modelo creado.

vgg19_model.summary()

_________________________________________________________________
Layer (type)                 Output Shape              Param #
=================================================================
input_2 (InputLayer)         (None, 48, 48, 3)         0
_________________________________________________________________
block1_conv1 (Conv2D)        (None, 48, 48, 64)        1792
_________________________________________________________________
block1_conv2 (Conv2D)        (None, 48, 48, 64)        36928
_________________________________________________________________
block1_pool (MaxPooling2D)   (None, 24, 24, 64)        0
_________________________________________________________________
block2_conv1 (Conv2D)        (None, 24, 24, 128)       73856
_________________________________________________________________
block2_conv2 (Conv2D)        (None, 24, 24, 128)       147584
_________________________________________________________________
block2_pool (MaxPooling2D)   (None, 12, 12, 128)       0
_________________________________________________________________
block3_conv1 (Conv2D)        (None, 12, 12, 256)       295168
_________________________________________________________________
block3_conv2 (Conv2D)        (None, 12, 12, 256)       590080
_________________________________________________________________
block3_conv3 (Conv2D)        (None, 12, 12, 256)       590080
_________________________________________________________________
block3_conv4 (Conv2D)        (None, 12, 12, 256)       590080
_________________________________________________________________
block3_pool (MaxPooling2D)   (None, 6, 6, 256)         0
_________________________________________________________________
block4_conv1 (Conv2D)        (None, 6, 6, 512)         1180160
_________________________________________________________________
block4_conv2 (Conv2D)        (None, 6, 6, 512)         2359808
_________________________________________________________________
block4_conv3 (Conv2D)        (None, 6, 6, 512)         2359808
_________________________________________________________________
block4_conv4 (Conv2D)        (None, 6, 6, 512)         2359808
_________________________________________________________________
block4_pool (MaxPooling2D)   (None, 3, 3, 512)         0
_________________________________________________________________
block5_conv1 (Conv2D)        (None, 3, 3, 512)         2359808
_________________________________________________________________
block5_conv2 (Conv2D)        (None, 3, 3, 512)         2359808
_________________________________________________________________
block5_conv3 (Conv2D)        (None, 3, 3, 512)         2359808
_________________________________________________________________
block5_conv4 (Conv2D)        (None, 3, 3, 512)         2359808
_________________________________________________________________
block5_pool (MaxPooling2D)   (None, 1, 1, 512)         0
_________________________________________________________________
flatten (Flatten)            (None, 512)               0
_________________________________________________________________
fc1 (Dense)                  (None, 4096)              2101248
_________________________________________________________________
fc2 (Dense)                  (None, 4096)              16781312
_________________________________________________________________
predictions (Dense)          (None, 100)               409700
=================================================================
Total params: 39,316,644
Trainable params: 39,316,644
Non-trainable params: 0

De 34 millones a 39. Ahora sólo queda entrenar.

vgg19 = vgg19_model.fit(x=x_train_resized, y=y_train, batch_size=32, epochs=10, verbose=1, validation_data=(x_test_resized, y_test), shuffle=True)
Train on 50000 samples, validate on 10000 samples
Epoch 1/10
50000/50000 [==============================] - 208s 4ms/step - loss: 4.6054 - acc: 0.0085 - mean_squared_error: 0.0099 - val_loss: 4.6051 - val_acc: 0.0113 - val_mean_squared_error: 0.0099
Epoch 2/10
 50000/50000 [==============================] - 207s 4ms/step - loss: 4.6053 - acc: 0.0094 - mean_squared_error: 0.0099 - val_loss: 4.6051 - val_acc: 0.0100 - val_mean_squared_error: 0.0099
Epoch 3/10
 50000/50000 [==============================] - 207s 4ms/step - loss: 4.6053 - acc: 0.0097 - mean_squared_error: 0.0099 - val_loss: 4.6051 - val_acc: 0.0154 - val_mean_squared_error: 0.0099
Epoch 4/10
 50000/50000 [==============================] - 206s 4ms/step - loss: 4.6052 - acc: 0.0106 - mean_squared_error: 0.0099 - val_loss: 4.6050 - val_acc: 0.0100 - val_mean_squared_error: 0.0099
Epoch 5/10
 50000/50000 [==============================] - 207s 4ms/step - loss: 4.6051 - acc: 0.0117 - mean_squared_error: 0.0099 - val_loss: 4.6047 - val_acc: 0.0152 - val_mean_squared_error: 0.0099
Epoch 6/10
 50000/50000 [==============================] - 207s 4ms/step - loss: 4.6046 - acc: 0.0149 - mean_squared_error: 0.0099 - val_loss: 4.6038 - val_acc: 0.0186 - val_mean_squared_error: 0.0099
Epoch 7/10
 50000/50000 [==============================] - 207s 4ms/step - loss: 4.6027 - acc: 0.0173 - mean_squared_error: 0.0099 - val_loss: 4.6003 - val_acc: 0.0169 - val_mean_squared_error: 0.0099
Epoch 8/10
 50000/50000 [==============================] - 207s 4ms/step - loss: 4.5682 - acc: 0.0182 - mean_squared_error: 0.0099 - val_loss: 4.4942 - val_acc: 0.0185 - val_mean_squared_error: 0.0099
Epoch 9/10
 50000/50000 [==============================] - 207s 4ms/step - loss: 4.4183 - acc: 0.0296 - mean_squared_error: 0.0099 - val_loss: 4.3578 - val_acc: 0.0315 - val_mean_squared_error: 0.0098
Epoch 10/10
 50000/50000 [==============================] - 207s 4ms/step - loss: 4.3185 - acc: 0.0362 - mean_squared_error: 0.0098 - val_loss: 4.2512 - val_acc: 0.0513 - val_mean_squared_error: 0.0098

Obviaremos la evaluación.

Veamos las métricas obtenidas para el entrenamiento y validación gráficamente.

plt.figure(0)
plt.plot(vgg19.history['acc'],'r')
plt.plot(vgg19.history['val_acc'],'g')
plt.xticks(np.arange(0, 11, 2.0))
plt.rcParams['figure.figsize'] = (8, 6)
plt.xlabel("Num of Epochs")
plt.ylabel("Accuracy")
plt.title("Training Accuracy vs Validation Accuracy")
plt.legend(['train','validation'])

plt.figure(1)
plt.plot(vgg19.history['loss'],'r')
plt.plot(vgg19.history['val_loss'],'g')
plt.xticks(np.arange(0, 11, 2.0))
plt.rcParams['figure.figsize'] = (8, 6)
plt.xlabel("Num of Epochs")
plt.ylabel("Loss")
plt.title("Training Loss vs Validation Loss")
plt.legend(['train','validation'])

plt.show()

Accuracy

Loss

La generalización mejora a un 1% aproximadamente respecto a la red convolucional del experimento anterior, si bien, después de 10 epochs no ha mejorado las métricas estándar.

Matriz de confusión

Pasemos ahora a ver la matriz de confusión y las métricas de Accuracy, Recall y F1-score.

Vamos a hacer una predicción sobre el dataset de validación y, a partir de ésta, generamos la matriz de confusión y mostramos las métricas mencionadas anteriormente.

vgg19_pred = vgg19_model.predict(x_test_resized, batch_size=32, verbose=1)
vgg19_predicted = np.argmax(vgg19_pred, axis=1)

Como ya hiciéramos en la primera parte, vamos a dar como predecida el mayor valor de la predicción. Lo normal es dar un valor mínimo o bias que defina un resultado como positivo, pero en este caso, lo vamos a hacer simple.

Con la librería Scikit Learn, generamos la matriz de confusión y la dibujamos (aunque el gráfico no es muy bueno debido al numero de etiquetas).

#Creamos la matriz de confusión
vgg19_cm = confusion_matrix(np.argmax(y_test, axis=1), vgg19_predicted)

# Visualiamos la matriz de confusión
vgg19_df_cm = pd.DataFrame(vgg19_cm, range(100), range(100))
plt.figure(figsize = (20,14))
sn.set(font_scale=1.4) #for label size
sn.heatmap(vgg19_df_cm, annot=True, annot_kws={"size": 12}) # font size
plt.show()

Matriz de confusión

Y por último, mostramos las métricas:

vgg19_report = classification_report(np.argmax(y_test, axis=1), vgg19_predicted)
print(vgg19_report)

             precision    recall  f1-score   support

          0       0.00      0.00      0.00       100
          1       0.00      0.00      0.00       100
          2       0.00      0.00      0.00       100
          3       0.00      0.00      0.00       100
          4       0.00      0.00      0.00       100
          5       0.00      0.00      0.00       100
          6       0.00      0.00      0.00       100
          7       0.00      0.00      0.00       100
          8       0.00      0.00      0.00       100
          9       0.00      0.00      0.00       100
         10       0.00      0.00      0.00       100
         11       0.00      0.00      0.00       100
         12       0.00      0.00      0.00       100
         13       0.00      0.00      0.00       100
         14       0.02      0.01      0.01       100
         15       0.00      0.00      0.00       100
         16       0.00      0.00      0.00       100
         17       0.07      0.08      0.07       100
         18       0.00      0.00      0.00       100
         19       0.00      0.00      0.00       100
         20       0.05      0.55      0.09       100
         21       0.11      0.07      0.09       100
         22       0.04      0.08      0.06       100
         23       0.00      0.00      0.00       100
         24       0.08      0.22      0.11       100
         25       0.00      0.00      0.00       100
         26       0.00      0.00      0.00       100
         27       0.00      0.00      0.00       100
         28       0.06      0.06      0.06       100
         29       0.00      0.00      0.00       100
         30       0.07      0.53      0.13       100
         31       0.02      0.02      0.02       100
         32       0.00      0.00      0.00       100
         33       0.00      0.00      0.00       100
         34       0.00      0.00      0.00       100
         35       0.00      0.00      0.00       100
         36       0.01      0.03      0.02       100
         37       0.00      0.00      0.00       100
         38       0.00      0.00      0.00       100
         39       0.07      0.04      0.05       100
         40       0.00      0.00      0.00       100
         41       0.03      0.04      0.04       100
         42       0.00      0.00      0.00       100
         43       0.04      0.28      0.08       100
         44       0.00      0.00      0.00       100
         45       0.00      0.00      0.00       100
         46       0.00      0.00      0.00       100
         47       0.08      0.25      0.13       100
         48       0.00      0.00      0.00       100
         49       0.07      0.33      0.12       100
         50       0.00      0.00      0.00       100
         51       0.00      0.00      0.00       100
         52       0.10      0.43      0.16       100
         53       0.04      0.79      0.08       100
         54       0.00      0.00      0.00       100
         55       0.04      0.01      0.02       100
         56       0.00      0.00      0.00       100
         57       0.00      0.00      0.00       100
         58       0.09      0.04      0.06       100
         59       0.00      0.00      0.00       100
         60       0.23      0.11      0.15       100
         61       0.00      0.00      0.00       100
         62       0.00      0.00      0.00       100
         63       0.00      0.00      0.00       100
         64       0.00      0.00      0.00       100
         65       0.00      0.00      0.00       100
         66       0.00      0.00      0.00       100
         67       0.00      0.00      0.00       100
         68       0.00      0.00      0.00       100
         69       0.00      0.00      0.00       100
         70       0.00      0.00      0.00       100
         71       0.07      0.10      0.08       100
         72       0.00      0.00      0.00       100
         73       0.00      0.00      0.00       100
         74       0.02      0.01      0.01       100
         75       0.05      0.11      0.07       100
         76       0.00      0.00      0.00       100
         77       0.00      0.00      0.00       100
         78       0.00      0.00      0.00       100
         79       0.00      0.00      0.00       100
         80       0.00      0.00      0.00       100
         81       0.04      0.09      0.05       100
         82       0.08      0.01      0.02       100
         83       0.00      0.00      0.00       100
         84       0.00      0.00      0.00       100
         85       0.04      0.04      0.04       100
         86       0.00      0.00      0.00       100
         87       0.00      0.00      0.00       100
         88       0.03      0.31      0.05       100
         89       0.00      0.00      0.00       100
         90       0.00      0.00      0.00       100
         91       0.00      0.00      0.00       100
         92       0.00      0.00      0.00       100
         93       0.00      0.00      0.00       100
         94       0.00      0.00      0.00       100
         95       0.11      0.25      0.15       100
         96       0.00      0.00      0.00       100
         97       0.04      0.24      0.07       100
         98       0.00      0.00      0.00       100
         99       0.00      0.00      0.00       100

avg / total       0.02      0.05      0.02     10000

Curva ROC (tasas de verdaderos positivos y falsos positivos)

Vamos a codificar la curva ROC:

from sklearn.datasets import make_classification
from sklearn.preprocessing import label_binarize
from scipy import interp
from itertools import cycle

n_classes = 100

from sklearn.metrics import roc_curve, auc

# Plot linewidth.
lw = 2

# Compute ROC curve and ROC area for each class
fpr = dict()
tpr = dict()
roc_auc = dict()
for i in range(n_classes):
    fpr[i], tpr[i], _ = roc_curve(y_test[:, i], vgg19_pred[:, i])
    roc_auc[i] = auc(fpr[i], tpr[i])

# Compute micro-average ROC curve and ROC area
fpr["micro"], tpr["micro"], _ = roc_curve(y_test.ravel(), vgg19_pred.ravel())
roc_auc["micro"] = auc(fpr["micro"], tpr["micro"])

# Compute macro-average ROC curve and ROC area

# First aggregate all false positive rates
all_fpr = np.unique(np.concatenate([fpr[i] for i in range(n_classes)]))

# Then interpolate all ROC curves at this points
mean_tpr = np.zeros_like(all_fpr)
for i in range(n_classes):
    mean_tpr += interp(all_fpr, fpr[i], tpr[i])

# Finally average it and compute AUC
mean_tpr /= n_classes

fpr["macro"] = all_fpr
tpr["macro"] = mean_tpr
roc_auc["macro"] = auc(fpr["macro"], tpr["macro"])

# Plot all ROC curves
plt.figure(1)
plt.plot(fpr["micro"], tpr["micro"],
         label='micro-average ROC curve (area = {0:0.2f})'
               ''.format(roc_auc["micro"]),
         color='deeppink', linestyle=':', linewidth=4)

plt.plot(fpr["macro"], tpr["macro"],
         label='macro-average ROC curve (area = {0:0.2f})'
               ''.format(roc_auc["macro"]),
         color='navy', linestyle=':', linewidth=4)

colors = cycle(['aqua', 'darkorange', 'cornflowerblue'])
for i, color in zip(range(n_classes-97), colors):
    plt.plot(fpr[i], tpr[i], color=color, lw=lw,
             label='ROC curve of class {0} (area = {1:0.2f})'
             ''.format(i, roc_auc[i]))

plt.plot([0, 1], [0, 1], 'k--', lw=lw)
plt.xlim([0.0, 1.0])
plt.ylim([0.0, 1.05])
plt.xlabel('False Positive Rate')
plt.ylabel('True Positive Rate')
plt.title('Some extension of Receiver operating characteristic to multi-class')
plt.legend(loc="lower right")
plt.show()


# Zoom in view of the upper left corner.
plt.figure(2)
plt.xlim(0, 0.2)
plt.ylim(0.8, 1)
plt.plot(fpr["micro"], tpr["micro"],
         label='micro-average ROC curve (area = {0:0.2f})'
               ''.format(roc_auc["micro"]),
         color='deeppink', linestyle=':', linewidth=4)

plt.plot(fpr["macro"], tpr["macro"],
         label='macro-average ROC curve (area = {0:0.2f})'
               ''.format(roc_auc["macro"]),
         color='navy', linestyle=':', linewidth=4)

colors = cycle(['aqua', 'darkorange', 'cornflowerblue'])
for i, color in zip(range(3), colors):
    plt.plot(fpr[i], tpr[i], color=color, lw=lw,
             label='ROC curve of class {0} (area = {1:0.2f})'
             ''.format(i, roc_auc[i]))

plt.plot([0, 1], [0, 1], 'k--', lw=lw)
plt.xlabel('False Positive Rate')
plt.ylabel('True Positive Rate')
plt.title('Some extension of Receiver operating characteristic to multi-class')
plt.legend(loc="lower right")
plt.show()

El resultado para tres clases se muestra en los siguientes gráficos.

Curva ROC para 3 clases

Zoom de la Curva ROC para 3 clases

Vamos a ver algunos resultados:

imgplot = plt.imshow(x_train_original[0])
plt.show()
print('class for image 1: ' + str(np.argmax(y_test[0])))
print('predicted:         ' + str(vgg19_predicted[0]))

Una vaca?

class for image 1: 49
predicted: 30

imgplot = plt.imshow(x_train_original[3])
plt.show()
print('class for image 3: ' + str(np.argmax(y_test[3])))
print('predicted:         ' + str(vgg19_predicted[3]))

Un hombre?

class for image 3: 51
predicted: 75

Salvaremos los datos del histórico de entrenamiento para compararlos con otros modelos:

#Histórico
with open(path_base + '/vgg19_history.txt', 'wb') as file_pi:
  pickle.dump(scnn.history, file_pi)

A continuación, cargaremos las métricas obtenidas de anteriores modelos y los comparamos con los resultados actuales:

with open(path_base + '/vgg16_history.txt', 'rb') as f:
  vgg16_history = pickle.load(f)

Ya lo tenemos en las variables correspondientes. Ahora, comparemos las gráficas:

plt.figure(0)
plt.plot(snn_history['val_acc'],'r')
plt.plot(scnn_history['val_acc'],'g')
plt.plot(vgg16_history['val_acc'],'b')
plt.plot(vgg19.history['val_acc'],'y')
plt.xticks(np.arange(0, 11, 2.0))
plt.rcParams['figure.figsize'] = (8, 6)
plt.xlabel("Num of Epochs")
plt.ylabel("Accuracy")
plt.title("Simple NN Accuracy vs simple CNN Accuracy")
plt.legend(['simple NN','CNN','VGG 16','VGG 19'])

Simple NN Vs CNN accuracy

plt.figure(0)
plt.plot(snn_history['val_loss'],'r')
plt.plot(scnn_history['val_loss'],'g')
plt.plot(vgg16.history['val_loss'],'b')
plt.plot(vgg19.history['val_loss'],'y')
plt.xticks(np.arange(0, 11, 2.0))
plt.rcParams['figure.figsize'] = (8, 6)
plt.xlabel("Num of Epochs")
plt.ylabel("Loss")
plt.title("Simple NN Loss vs simple CNN Loss")
plt.legend(['simple NN','CNN','VGG 16','VGG 19'])

Simple NN Vs CNN loss

plt.figure(0)
plt.plot(snn_history['val_mean_squared_error'],'r')
plt.plot(scnn_history['val_mean_squared_error'],'g')
plt.plot(vgg16.history['val_mean_squared_error'],'b')
plt.plot(vgg19.history['val_mean_squared_error'],'y')
plt.xticks(np.arange(0, 11, 2.0))
plt.rcParams['figure.figsize'] = (8, 6)
plt.xlabel("Num of Epochs")
plt.ylabel("Mean Squared Error")
plt.title("Simple NN MSE vs simple CNN MSE")
plt.legend(['simple NN','CNN','VGG 16','VGG 19'])

Simple NN Vs CNN MSE

¿Qué ha pasado?

Bien, la respuesta es sencilla. Hemos querido usar un modelo predeterminado, obligándonos a modificar la imagen original haciéndola más grande. Como la imagen es de 32x32 píxeles, pues la imagen resultante queda peor y aprende peor. Esto es, hemos cambiado el ámbito de los datos con respecto a los experimentos anteriores.

Así que lo que tenemos que hacer, es una red VGG que no necesite modificar la imagen original.

Custom VGG

Definamos el modelo más específicamente:

def VGG16_Without_lastPool(include_top=True, input_tensor=None, input_shape=(32,32,3), pooling=None, classes=100):
    if input_tensor is None:
        img_input = Input(shape=input_shape)
    else:
        if not K.is_keras_tensor(input_tensor):
            img_input = Input(tensor=input_tensor, shape=input_shape)
        else:
            img_input = input_tensor
    # Block 1
    x = Conv2D(64, (3, 3), activation='relu', padding='same', name='block1_conv1')(img_input)
    x = Conv2D(64, (3, 3), activation='relu', padding='same', name='block1_conv2')(x)
    x = MaxPooling2D((2, 2), strides=(2, 2), name='block1_pool')(x)  #to 16x16

    # Block 2
    x = Conv2D(128, (3, 3), activation='relu', padding='same', name='block2_conv1')(x)
    x = Conv2D(128, (3, 3), activation='relu', padding='same', name='block2_conv2')(x)
    x = MaxPooling2D((2, 2), strides=(2, 2), name='block2_pool')(x) #to 8x8

    # Block 3
    x = Conv2D(256, (3, 3), activation='relu', padding='same', name='block3_conv1')(x)
    x = Conv2D(256, (3, 3), activation='relu', padding='same', name='block3_conv2')(x)
    x = Conv2D(256, (3, 3), activation='relu', padding='same', name='block3_conv3')(x)
    x = MaxPooling2D((2, 2), strides=(2, 2), name='block3_pool')(x) #to 4x4

    # Block 4
    x = Conv2D(512, (3, 3), activation='relu', padding='same', name='block4_conv1')(x)
    x = Conv2D(512, (3, 3), activation='relu', padding='same', name='block4_conv2')(x)
    x = Conv2D(512, (3, 3), activation='relu', padding='same', name='block4_conv3')(x)
    x = MaxPooling2D((2, 2), strides=(2, 2), name='block4_pool')(x) #to 2x2

    # Block 5
    x = Conv2D(512, (3, 3), activation='relu', padding='same', name='block5_conv1')(x)
    x = Conv2D(512, (3, 3), activation='relu', padding='same', name='block5_conv2')(x)
    x = Conv2D(512, (3, 3), activation='relu', padding='same', name='block5_conv3')(x)
    #x = MaxPooling2D((2, 2), strides=(2, 2), name='block5_pool')(x)

    if include_top:
        # Classification block
        x = Flatten(name='flatten')(x)
        x = Dense(4096, activation='relu', name='fc1')(x)
        x = Dense(4096, activation='relu', name='fc2')(x)
        x = Dense(classes, activation='softmax', name='predictions')(x)
    else:
        if pooling == 'avg':
            x = GlobalAveragePooling2D()(x)
        elif pooling == 'max':
            x = GlobalMaxPooling2D()(x)


    # Create model.
    model = Model(img_input, x, name='vgg16Bis')

    return model

Compilamos como hasta ahora...

def create_vgg16WithoutPool():
  model = VGG16_Without_lastPool(include_top=True, input_tensor=None, input_shape=(32,32,3), pooling=None, classes=100)

  return model

vgg16Bis_model = create_vgg16WithoutPool()
vgg16Bis_model.compile(loss='categorical_crossentropy', optimizer='sgd', metrics=['acc', 'mse'])

Una vez hecho esto, vamos a ver un resumen del modelo creado:

vgg16Bis_model.summary()

_________________________________________________________________
Layer (type)                 Output Shape              Param #
=================================================================
input_3 (InputLayer)         (None, 32, 32, 3)         0
_________________________________________________________________
block1_conv1 (Conv2D)        (None, 32, 32, 64)        1792
_________________________________________________________________
block1_conv2 (Conv2D)        (None, 32, 32, 64)        36928
_________________________________________________________________
block1_pool (MaxPooling2D)   (None, 16, 16, 64)        0
_________________________________________________________________
block2_conv1 (Conv2D)        (None, 16, 16, 128)       73856
_________________________________________________________________
block2_conv2 (Conv2D)        (None, 16, 16, 128)       147584
_________________________________________________________________
block2_pool (MaxPooling2D)   (None, 8, 8, 128)         0
_________________________________________________________________
block3_conv1 (Conv2D)        (None, 8, 8, 256)         295168
_________________________________________________________________
block3_conv2 (Conv2D)        (None, 8, 8, 256)         590080
_________________________________________________________________
block3_conv3 (Conv2D)        (None, 8, 8, 256)         590080
_________________________________________________________________
block3_pool (MaxPooling2D)   (None, 4, 4, 256)         0
_________________________________________________________________
block4_conv1 (Conv2D)        (None, 4, 4, 512)         1180160
_________________________________________________________________
block4_conv2 (Conv2D)        (None, 4, 4, 512)         2359808
_________________________________________________________________
block4_conv3 (Conv2D)        (None, 4, 4, 512)         2359808
_________________________________________________________________
block4_pool (MaxPooling2D)   (None, 2, 2, 512)         0
_________________________________________________________________
block5_conv1 (Conv2D)        (None, 2, 2, 512)         2359808
_________________________________________________________________
block5_conv2 (Conv2D)        (None, 2, 2, 512)         2359808
_________________________________________________________________
block5_conv3 (Conv2D)        (None, 2, 2, 512)         2359808
_________________________________________________________________
flatten (Flatten)            (None, 2048)              0
_________________________________________________________________
fc1 (Dense)                  (None, 4096)              8392704
_________________________________________________________________
fc2 (Dense)                  (None, 4096)              16781312
_________________________________________________________________
predictions (Dense)          (None, 100)               409700
=================================================================
Total params: 40,298,404
Trainable params: 40,298,404
Non-trainable params: 0

Tenemos uno más, 40 millones de parámetros, porque en realidad, sólo hemos quitado el Pool del bloque 5. Ahora sólo queda entrenar, pero esta vez con el dataset original normalizado:

vgg16Bis = vgg16Bis_model.fit(x=x_train, y=y_train, batch_size=32, epochs=10, verbose=1, validation_data=(x_test, y_test), shuffle=True)
Train on 50000 samples, validate on 10000 samples
Epoch 1/10
50000/50000 [==============================] - 139s 3ms/step - loss: 4.6053 - acc: 0.0093 - mean_squared_error: 0.0099 - val_loss: 4.6051 - val_acc: 0.0100 - val_mean_squared_error: 0.0099
Epoch 2/10
 50000/50000 [==============================] - 137s 3ms/step - loss: 4.6053 - acc: 0.0100 - mean_squared_error: 0.0099 - val_loss: 4.6050 - val_acc: 0.0099 - val_mean_squared_error: 0.0099
Epoch 3/10
 50000/50000 [==============================] - 137s 3ms/step - loss: 4.6051 - acc: 0.0105 - mean_squared_error: 0.0099 - val_loss: 4.6048 - val_acc: 0.0174 - val_mean_squared_error: 0.0099
Epoch 4/10
 50000/50000 [==============================] - 138s 3ms/step - loss: 4.6048 - acc: 0.0119 - mean_squared_error: 0.0099 - val_loss: 4.6042 - val_acc: 0.0198 - val_mean_squared_error: 0.0099
Epoch 5/10
 50000/50000 [==============================] - 137s 3ms/step - loss: 4.6036 - acc: 0.0210 - mean_squared_error: 0.0099 - val_loss: 4.6020 - val_acc: 0.0228 - val_mean_squared_error: 0.0099
Epoch 6/10
 50000/50000 [==============================] - 137s 3ms/step - loss: 4.5910 - acc: 0.0231 - mean_squared_error: 0.0099 - val_loss: 4.4990 - val_acc: 0.0203 - val_mean_squared_error: 0.0099
Epoch 7/10
 50000/50000 [==============================] - 138s 3ms/step - loss: 4.4632 - acc: 0.0217 - mean_squared_error: 0.0099 - val_loss: 4.4322 - val_acc: 0.0227 - val_mean_squared_error: 0.0099
Epoch 8/10
 50000/50000 [==============================] - 138s 3ms/step - loss: 4.3865 - acc: 0.0261 - mean_squared_error: 0.0098 - val_loss: 4.3199 - val_acc: 0.0315 - val_mean_squared_error: 0.0098
Epoch 9/10
 50000/50000 [==============================] - 137s 3ms/step - loss: 4.2913 - acc: 0.0300 - mean_squared_error: 0.0098 - val_loss: 4.2396 - val_acc: 0.0348 - val_mean_squared_error: 0.0098
Epoch 10/10
 50000/50000 [==============================] - 138s 3ms/step - loss: 4.2151 - acc: 0.0363 - mean_squared_error: 0.0098 - val_loss: 4.3424 - val_acc: 0.0256 - val_mean_squared_error: 0.0098

Veamos las métricas obtenidas para el entrenamiento y validación gráficamente:

plt.figure(0)
plt.plot(vgg16Bis.history['acc'],'r')
plt.plot(vgg16Bis.history['val_acc'],'g')
plt.xticks(np.arange(0, 11, 2.0))
plt.rcParams['figure.figsize'] = (8, 6)
plt.xlabel("Num of Epochs")
plt.ylabel("Accuracy")
plt.title("Training Accuracy vs Validation Accuracy")
plt.legend(['train','validation'])

plt.figure(1)
plt.plot(vgg16Bis.history['loss'],'r')
plt.plot(vgg16Bis.history['val_loss'],'g')
plt.xticks(np.arange(0, 11, 2.0))
plt.rcParams['figure.figsize'] = (8, 6)
plt.xlabel("Num of Epochs")
plt.ylabel("Loss")
plt.title("Training Loss vs Validation Loss")
plt.legend(['train','validation'])

plt.show()

Accuracy

Loss

Después de 10 epochs no han mejorado las métricas estándar.

Matriz de confusión

Pasemos ahora a ver la matriz de confusión y las métricas de Accuracy, Recall y F1-score.

Vamos a hacer una predicción sobre el dataset de validación y, a partir de ésta, generamos la matriz de confusión y mostramos las métricas mencionadas anteriormente:

vgg16Bis_pred = vgg16Bis_model.predict(x_test, batch_size=32, verbose=1)
vgg16Bis_predicted = np.argmax(vgg16Bis_pred, axis=1)

vgg_cm = confusion_matrix(np.argmax(y_test, axis=1), vgg16Bis_predicted)

# Visualizing of confusion matrix
vgg_df_cm = pd.DataFrame(vgg_cm, range(100), range(100))
plt.figure(figsize = (20,14))
sn.set(font_scale=1.4) #for label size
sn.heatmap(vgg_df_cm, annot=True, annot_kws={"size": 12}) # font size
plt.show()

Matriz de confusión

Y por último, mostramos las métricas:

vgg_report = classification_report(np.argmax(y_test, axis=1), vgg16Bis_predicted)
print(vgg_report)

             precision    recall  f1-score   support

          0       0.32      0.34      0.33       100
          1       0.19      0.22      0.20       100
          2       0.23      0.14      0.17       100
          3       0.11      0.02      0.03       100
          4       0.03      0.02      0.02       100
          5       0.13      0.08      0.10       100
          6       0.21      0.19      0.20       100
          7       0.13      0.17      0.15       100
          8       0.11      0.10      0.10       100
          9       0.14      0.24      0.18       100
         10       0.00      0.00      0.00       100
         11       0.09      0.14      0.11       100
         12       0.18      0.02      0.04       100
         13       0.14      0.02      0.04       100
         14       0.25      0.08      0.12       100
         15       0.10      0.05      0.07       100
         16       0.31      0.11      0.16       100
         17       0.15      0.42      0.22       100
         18       0.16      0.32      0.21       100
         19       0.10      0.05      0.07       100
         20       0.28      0.30      0.29       100
         21       0.08      0.29      0.13       100
         22       0.00      0.00      0.00       100
         23       0.18      0.46      0.26       100
         24       0.25      0.30      0.27       100
         25       0.06      0.01      0.02       100
         26       0.04      0.01      0.02       100
         27       0.07      0.08      0.07       100
         28       0.28      0.24      0.26       100
         29       0.23      0.08      0.12       100
         30       0.17      0.12      0.14       100
         31       0.07      0.11      0.09       100
         32       0.19      0.03      0.05       100
         33       0.20      0.12      0.15       100
         34       0.12      0.19      0.15       100
         35       0.15      0.07      0.10       100
         36       0.12      0.04      0.06       100
         37       0.10      0.10      0.10       100
         38       0.09      0.08      0.08       100
         39       0.00      0.00      0.00       100
         40       0.17      0.03      0.05       100
         41       0.28      0.51      0.36       100
         42       0.12      0.13      0.12       100
         43       0.18      0.30      0.23       100
         44       0.17      0.02      0.04       100
         45       0.00      0.00      0.00       100
         46       0.18      0.07      0.10       100
         47       0.20      0.50      0.28       100
         48       0.30      0.11      0.16       100
         49       0.20      0.13      0.16       100
         50       0.00      0.00      0.00       100
         51       0.10      0.09      0.10       100
         52       0.32      0.26      0.29       100
         53       0.59      0.13      0.21       100
         54       0.14      0.53      0.23       100
         55       0.00      0.00      0.00       100
         56       0.14      0.32      0.19       100
         57       0.37      0.10      0.16       100
         58       0.13      0.14      0.14       100
         59       0.20      0.03      0.05       100
         60       0.37      0.71      0.49       100
         61       0.13      0.20      0.16       100
         62       0.20      0.57      0.30       100
         63       0.10      0.28      0.15       100
         64       0.00      0.00      0.00       100
         65       0.16      0.06      0.09       100
         66       0.10      0.01      0.02       100
         67       0.16      0.05      0.08       100
         68       0.36      0.47      0.41       100
         69       0.16      0.29      0.21       100
         70       0.32      0.08      0.13       100
         71       0.25      0.35      0.29       100
         72       0.00      0.00      0.00       100
         73       0.20      0.50      0.28       100
         74       0.05      0.12      0.07       100
         75       0.08      0.30      0.12       100
         76       0.17      0.55      0.26       100
         77       0.08      0.01      0.02       100
         78       0.22      0.02      0.04       100
         79       0.15      0.02      0.04       100
         80       0.08      0.05      0.06       100
         81       0.11      0.10      0.11       100
         82       0.59      0.43      0.50       100
         83       0.06      0.01      0.02       100
         84       0.09      0.06      0.07       100
         85       0.19      0.12      0.15       100
         86       0.13      0.37      0.19       100
         87       0.09      0.08      0.08       100
         88       0.01      0.01      0.01       100
         89       0.12      0.08      0.09       100
         90       0.15      0.12      0.13       100
         91       0.25      0.37      0.30       100
         92       0.18      0.10      0.13       100
         93       0.13      0.11      0.12       100
         94       0.18      0.26      0.21       100
         95       0.23      0.16      0.19       100
         96       0.12      0.06      0.08       100
         97       0.08      0.07      0.08       100
         98       0.05      0.04      0.04       100
         99       0.18      0.19      0.19       100

avg / total       0.16      0.16      0.14     10000

Curva ROC (tasas de verdaderos positivos y falsos positivos)

Vamos a codificar de nuevo la curva ROC:

from sklearn.datasets import make_classification
from sklearn.preprocessing import label_binarize
from scipy import interp
from itertools import cycle

n_classes = 100

from sklearn.metrics import roc_curve, auc

# Plot linewidth.
lw = 2

# Compute ROC curve and ROC area for each class
fpr = dict()
tpr = dict()
roc_auc = dict()
for i in range(n_classes):
    fpr[i], tpr[i], _ = roc_curve(y_test[:, i], vgg16Bis_pred[:, i])
    roc_auc[i] = auc(fpr[i], tpr[i])

# Compute micro-average ROC curve and ROC area
fpr["micro"], tpr["micro"], _ = roc_curve(y_test.ravel(), vgg16Bis_pred.ravel())
roc_auc["micro"] = auc(fpr["micro"], tpr["micro"])

# Compute macro-average ROC curve and ROC area

# First aggregate all false positive rates
all_fpr = np.unique(np.concatenate([fpr[i] for i in range(n_classes)]))

# Then interpolate all ROC curves at this points
mean_tpr = np.zeros_like(all_fpr)
for i in range(n_classes):
    mean_tpr += interp(all_fpr, fpr[i], tpr[i])

# Finally average it and compute AUC
mean_tpr /= n_classes

fpr["macro"] = all_fpr
tpr["macro"] = mean_tpr
roc_auc["macro"] = auc(fpr["macro"], tpr["macro"])

# Plot all ROC curves
plt.figure(1)
plt.plot(fpr["micro"], tpr["micro"],
         label='micro-average ROC curve (area = {0:0.2f})'
               ''.format(roc_auc["micro"]),
         color='deeppink', linestyle=':', linewidth=4)

plt.plot(fpr["macro"], tpr["macro"],
         label='macro-average ROC curve (area = {0:0.2f})'
               ''.format(roc_auc["macro"]),
         color='navy', linestyle=':', linewidth=4)

colors = cycle(['aqua', 'darkorange', 'cornflowerblue'])
for i, color in zip(range(n_classes-97), colors):
    plt.plot(fpr[i], tpr[i], color=color, lw=lw,
             label='ROC curve of class {0} (area = {1:0.2f})'
             ''.format(i, roc_auc[i]))

plt.plot([0, 1], [0, 1], 'k--', lw=lw)
plt.xlim([0.0, 1.0])
plt.ylim([0.0, 1.05])
plt.xlabel('False Positive Rate')
plt.ylabel('True Positive Rate')
plt.title('Some extension of Receiver operating characteristic to multi-class')
plt.legend(loc="lower right")
plt.show()


# Zoom in view of the upper left corner.
plt.figure(2)
plt.xlim(0, 0.2)
plt.ylim(0.8, 1)
plt.plot(fpr["micro"], tpr["micro"],
         label='micro-average ROC curve (area = {0:0.2f})'
               ''.format(roc_auc["micro"]),
         color='deeppink', linestyle=':', linewidth=4)

plt.plot(fpr["macro"], tpr["macro"],
         label='macro-average ROC curve (area = {0:0.2f})'
               ''.format(roc_auc["macro"]),
         color='navy', linestyle=':', linewidth=4)

colors = cycle(['aqua', 'darkorange', 'cornflowerblue'])
for i, color in zip(range(3), colors):
    plt.plot(fpr[i], tpr[i], color=color, lw=lw,
             label='ROC curve of class {0} (area = {1:0.2f})'
             ''.format(i, roc_auc[i]))

plt.plot([0, 1], [0, 1], 'k--', lw=lw)
plt.xlabel('False Positive Rate')
plt.ylabel('True Positive Rate')
plt.title('Some extension of Receiver operating characteristic to multi-class')
plt.legend(loc="lower right")
plt.show()

El resultado para tres clases se muestra en los siguientes gráficos:

Curva ROC para 3 clases

Zoom de la Curva ROC para 3 clases

Salvaremos los datos del histórico de entrenamiento para compararlos con otros modelos:

#Histórico
with open(path_base + '/cvgg16_history.txt', 'wb') as file_pi:
  pickle.dump(scnn.history, file_pi)

A continuación, vamos a comparar las métricas con los modelos anteriores:

plt.figure(0)
plt.plot(snn_history['val_acc'],'r')
plt.plot(scnn_history['val_acc'],'g')
plt.plot(vgg16.history['val_acc'],'b')
plt.plot(vgg19.history['val_acc'],'y')
plt.plot(vgg16Bis.history['val_acc'],'m')
plt.xticks(np.arange(0, 11, 2.0))
plt.rcParams['figure.figsize'] = (8, 6)
plt.xlabel("Num of Epochs")
plt.ylabel("Accuracy")
plt.title("Simple NN Accuracy vs simple CNN Accuracy")
plt.legend(['simple NN','CNN','VGG 16','VGG 19','Custom VGG'])

Simple NN Vs CNN accuracy

plt.figure(0)
plt.plot(snn_history['val_loss'],'r')
plt.plot(scnn_history['val_loss'],'g')
plt.plot(vgg16.history['val_loss'],'b')
plt.plot(vgg19.history['val_loss'],'y')
plt.plot(vgg16Bis.history['val_loss'],'m')
plt.xticks(np.arange(0, 11, 2.0))
plt.rcParams['figure.figsize'] = (8, 6)
plt.xlabel("Num of Epochs")
plt.ylabel("Loss")
plt.title("Simple NN Loss vs simple CNN Loss")
plt.legend(['simple NN','CNN','VGG 16','VGG 19','Custom VGG'])

Simple NN Vs CNN loss

plt.figure(0)
plt.plot(snn_history['val_mean_squared_error'],'r')
plt.plot(scnn_history['val_mean_squared_error'],'g')
plt.plot(vgg16.history['val_mean_squared_error'],'b')
plt.plot(vgg19.history['val_mean_squared_error'],'y')
plt.plot(vgg16Bis.history['val_mean_squared_error'],'m')
plt.xticks(np.arange(0, 11, 2.0))
plt.rcParams['figure.figsize'] = (8, 6)
plt.xlabel("Num of Epochs")
plt.ylabel("Mean Squared Error")
plt.title("Simple NN MSE vs simple CNN MSE")
plt.legend(['simple NN','CNN','VGG 16','VGG 19','Custom VGG'])

Simple NN Vs CNN MSE

Conclusión sobre el segundo experimento

Hemos visto unos modelos más profundos, en los que el número de parámetros ha aumentado en exceso incluso para una red convolutiva. Además, el aprendizaje es mucho más lento en este caso específico. Quizás, a la vista de los resultados, sería planteable aumentar el número de epochs a realizar, pero en cambio, sabemos que actualmente existen modelos mejores que vamos a ver.

En el siguiente artículo, presentaremos la arquitectura: ResNet.

¡Síguenos en Twitter para no perderte ni un post!

Jesús Utrera Burgal
Autor

Jesús Utrera Burgal

Desarrollador .NET por más de 10 años, en los últimos años me he adentrado en el mundo de Machine Learning, concretamente en el área de Supervised Deep Learning.
